General Platform Technology Intel Centrino
System Type Notebook
Built-in Devices Stereo speakers, wireless LAN antenna, SmartCard reader/writer, Bluetooth antenna
Width 12.4 in
Depth 10.1 in
Height 1.1 in
Weight 5.1 lbs
Processor
Processor Intel Pentium M 740 / 1.73 GHz
Data Bus Speed 533 MHz
Features Enhanced SpeedStep technology, power-optimized processor system bus, Execute Disable Bit capability
Chipset Type Mobile Intel 915GM Express
Cache Memory
Type L2 cache
Installed Size 2 MB
RAM
Installed Size 512 MB / 2 GB (max)
Technology DDR2 SDRAM - 400 MHz
Memory Specification Compliance PC2-3200
Form Factor SO DIMM 200-pin
Storage Controller
Type IDE
Storage
Hard Drive 40 GB - 5400 rpm
Optical Storage
Type CD-RW / DVD-ROM combo - removable plug-in module
Read Speed 24x (CD) / 8x (DVD)
Write Speed 24x
Rewrite Speed 10x
Card Reader
Type Card reader
Supported Flash Memory Cards SD Memory Card, MultiMediaCard
Display
Display Type 14.1" TFT
Max Resolution 1024 x 768 ( XGA )
Widescreen Display No
Color Support 24-bit (16.7 million colors)
Video
Graphics Processor / Vendor Intel GMA 900 Dynamic Video Memory Technology 3.0
Audio
Audio Output Sound card
Compliant Standards AC ''97, Sound Blaster Pro
Audio Input Microphone
Input Device(s)
Type Keyboard, touchpad, pointing stick
Telecom
Modem Fax / modem - MDC
Max Transfer Rate 56 Kbps
Protocols & Specifications ITU V.21, Bell 212A, ITU V.22, ITU V.22bis, ITU V.29, ITU V.32, ITU V.32bis, ITU V.34, ITU V.90, ITU V.17, ITU V.23, ITU V.27ter, ITU V.8bis, Bell 103J, ITU V.92, ITU T.30, ITU T.4, ITU V.250, ITU V.251, ITU V.80
Fax Compatibility G3
Networking
Networking Network adapter
Wireless LAN Supported Yes
Wireless NIC Intel PRO/Wireless 2200BG
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, Bluetooth, IEEE 802.11b, IEEE 802.11g
Remote Management Protocol SNMP
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, Bluetooth 1.1, IEEE 802.3x, IEEE 802.11g, IEEE 802.1x, Wi-Fi CERTIFIED
Expansion / Connectivity
Expansion Bays 1 x MultiBay II
Expansion Slots Total (Free) 1 ( 1 ) x CardBus - type I/II 1 ( 1 ) x SD Memory Card 2 ( 1 ) x memory - SO DIMM 200-pin 1 ( 1 ) x Smart Card
Interfaces 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) 1 x microphone - input - mini-phone stereo 3.5 mm 1 x audio - line-out/headphones - mini-phone stereo 3.5 mm 1 x modem - phone line - RJ-11 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 1 x infrared - IrDA 1 x serial - RS-232 - 9 pin D-Sub (DB-9) 1 x display / video - S-video output 3 x Hi-Speed USB - 4 pin USB Type A 1 x docking / port replicator
Miscellaneous
Features Security lock slot (cable lock sold separately), system password, power-on password, remote boot control, DriveLock, InstantOn, wake on LAN, memory change alert, ownership tag
Compliant Standards ACPI, APM 1.2, CE, CSA, UL, TUV GS, BSMI, CTR 21, GOST, CCIB, NEMKO, NORDIC, SABS, SASO, CISPR 22, ICES-003 Class B, FCC Part 15 B, FCC Part 68, CCC, MIC
Power
Power Device External
Voltage Required AC 120/230 V ( 50/60 Hz )
Battery
Technology Lithium ion
Installed Qty 1 / 2 (max)
Capacity 52 Wh
Run Time (Up To) 4.5 hour(s)
Operating System / Software
OS Provided Microsoft Windows XP Professional
Software Drivers & Utilities, Adobe Acrobat Reader, Norton AntiVirus, HP One-Button Disaster Recovery, InterVideo WinDVD, Sonic RecordNow, HP Client Manager Software 6.0, HP ProtectTools Security Manager, HP ProtectTools Smartcard Manager
Environmental Standards
ENERGY STAR Qualified Yes
Manufacturer Warranty
Service & Support 3 years warranty
Service & Support Details Limited warranty - parts and labor - 3 years
Environmental Parameters
Min Operating Temperature 41 °F
Max Operating Temperature 95 °F
Humidity Range Operating 10 - 90%
Shock Tolerance 125 g @ 2ms half-sine pulse (operating) / 200 g @ 2ms half-sine pulse (non-operating)
Vibration Tolerance 0.75 g @ RMS (random) (operating) / 1.5 g @ RMS (random) (non-operating)
Universal Product Identifiers
Brand Hewlett-Packard
Part Numbers PU982AW, PU982AW#B1L, PU982ET, PY424EA
GTIN 00829160810478.
